With the development of blow molding technology, as well as the demand for higher quality of plastic pallets, blow molding pallets are gradually replacing wooden pallets and injection pallets, blow molding pallets are gradually developing in the market. These include petrochemical, tobacco, food, medicine and transportation and so on, which the number of use blow molding pallets are doubled and redoubled. Blow molding pallets have great market potential.
Model | Unit | BM2000 | BM2000F |
Die head structure | Accumulating Type | ||
Main screw diameter | mm | 150 | 120*2 |
Max. plasticizing capacity (PE) | kg/h | 750-850 | 800-900 |
Driving motor | kW | 185 | 132*2 |
Accumulating volume | L | 75 | 120 |
Oil pump motor power | kW | 54.5 | 54.5 |
Clamping force | KN | 1200 | 1300 |
Max. space between platen | mm | 750-1950 | 750-1950 |
Platen size W*H | mm | 1600*1800 | 1600*1800 |
Max. mould size | mm | 1400*1800 | 1400*1800 |
Heating power of die head | kW | 79.6 | 101 |
Machine dimension L*W*H | m | 10.2*8.6*7.3 | 12*9.5*7.8 |
Machine weight | T | 50 | 62 |
Total power | kW | 365 | 480 |
1. High bearing capacity: when the blowing pallet and wooden pallet are the same weight, the load capacity of blow molding pallet is five- fold as much as wood pallet, which has improved the bearing capacity of the pallet and reduce the use of pallet. It improves the efficiency and cut the cost. What is more, the dynamic load of blow molding pallet is up to2 tons and the static load is 4 tons.
2. Long service year: It got a long service life, which can be used for more than 5 years in general; it can take up to 2 years in bad condition. It is 4-5 times of wooden pallet, about 2-3 times of injection pallet.
3. Specificity: They divided in two forms, about single face and double-faced. According to different bearing capacity requirements, its weight can be controlled in production, which is reduce the cost of materials. It is suitable for all industries, such as food, beverage, pharmaceuticals industry and other industries, it also can be customized for special requirements according to different factories.
4. High security: non-combustion, non-conductive, non-static, non-skid and no other auxiliary connection. That can ensure the safety of goods and operators.
5. Good quality: the blow molding pallet is strong in toughness and shatter-resistant. If it falls from the place that 3 meters high, it will be safe. Even if it hits by the forklift, it will not be broken.
6. Economical: That can be used recycled plastics, JWELL JWZ- BM500/1000 molding machine can be multi-purpose. It will help customers reduce investment costs, and it has low mold cost.
7. Environmental protection: the blow molding pallet is non-toxic, tasteless and anti-corrosion. Then the waste pallet can be recycled and utilized, this is good for the environment.
Suitable for producing different kinds of pallets;
Optional bottom sealing, product eject,core-pulling movement elements;
Adopt high output extrusion system, accumulating die head;
Hydraulic Servo control system.
Jwell started manufacturing screws and barrels in 1978, making it one of the earliest screw and barrel manufacturers in China. Its brand, "Jinhailuo", has become well recognized in the industry. In 1997, Jwell was established to begin the production of extrusion machinery. Today, Jwell is the vice president unit of the China Plastics Machinery Industry Association and one of the technology leaders in the extrusion machinery industry.
